SVPRO 2MP Global Shutter USB Camera Board 90fps High-Speed Webcam Module with Fisheye Lens Wide-Angle Slow-Motion Camera 1920x1200 AR0234 UVC Cam for Computers, Laptops, Android Devices
Product details
| Management number | 228848119 | Release Date | 2026/05/31 | List Price | US$32.80 | Model Number | 228848119 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification of Svpro 1200P Global Shutter USB Camera Module: Camera. Sensor: 1/2.6" (4:3) Aptina AR0234 Global Shutter Resolution: 1920 (H) x 1200 (V). Compression format: Mjpeg,YUYV Minimum illumination: 0.3 lux. Resolution and frame rate: 1920x1200 @ 90fps MJPEG/ 1920x1080 @ 90fps MJPEG 1600x1200 @ 90fps MJPEG/ 1280x960 @ 90fps MJPEG 1280x720 @ 90fps MJPEG/ 1024x768 @ 90fps MJPEG 960x720 @ 90fps MJPEG/ 800x600@ 90fps MJPEG 640x480 @ 90fps MJPEG/ 320x20x40 @ 90fps MJPEG. Lens: field of view: horizontal angle 153 degrees, M12 mount Adjustable parameters: brightness, contrast, saturation, hue, sharpness, gamma, white balance, backlight compensation, exposure Compatible Operating System: WinXP/Vista/Win7/Win8/Win9/Win10/Win11 etc., Linux with UVC (from Linux-2.6.26), MAC-OS X 10.4.8 or higher, Android 4.0 or higher with UVC. Plug and play for PC computer, laptop, Amcap, OpenCV, VLC, V4L2, Jetson Nano, Ubuntu, fswebcam, Facetime, Camerafi, USB camera, OBS, Xbox one, Zoom etc. Performance and others: Power supply type: USB BUS POWER,4P-2.0mm female Operating voltage: DC 5 V. Working current: 160 mA - 190 mA. Working temperature: 0°C ~ 60°C. Storage temperature: -20°C ~ 80°C. Board size: 38 x 38 mm. Weight: 30 g. USB cable: USB 2.0 type A port, cable length 1 meter
- Global shutter: Capture moving objects at high speed in razor-sharp images. Avoid rolling artifacts to get a much more accurate overall image than rolling shutter cameras.
- HD resolution: 2MP 1920x1200 90fps, fast frame for high speed shooting of moving objects. 1080P usb camera module with 1/2.6" Aptina AR0234 quality sensor for sharp, clear images. Note: Please change the preset frame rate in the software to meet your requirements for a higher frame rate.
- M12 fisheye lens: Wide-angle field of view about 153 degrees, the small sized camera board (38mmx38mm) can be installed in most narrow positions and can be used in any industrial and DIY video system.
- Plug & Play: UVC compatible, simply connect the camera to PC, laptop,respberry pi and Android device with the USB cable without installing additional drivers.
- Applications: The sensor's high resolution, excellent low-light sensitivity and low-distortion lens enable exceptionally accurate gaze and eye tracking, highly recommended for motion analysis,augmented and virtual reality, gesture and eye tracking, iris and physiognomy recognition, depth and motion detection
| ASIN | B0D4TXKBNR |
|---|---|
| Brand | SVPRO |
| Color | FOV 153 ° (Fisheye), M12 Lens |
| Features | Global Shutter, High Speed 90fps, Slow Motion, Wide Angle, Fisheye |
| Lens Type | Wide Angle |
| Model Name | High Speed global shutter camera |
| Style Name | Distortion-free lens, field of view 126° |
| Sensor Type | CMOS |
| Manufacturer | Svpro |
| Model Number | SV-USBGS1200P01-L170 |
| BuiltIn Media | 1* camera module with 1.5M USB cable, 1* instruction |
| Camcorder Type | Webcam |
| Antenna Location | high speed camera, golf swing camera, montion analysis camera, eye traking camera face recognition camera, machine vision camera, industrial camera,usb security camera |
| Maximum Aperture | 1.4 Millimeters |
| Video Resolution | 1200p |
| Flash Memory Type | non |
| Photo Sensor Size | 1/2.6-inch |
| Compatible Devices | Laptop, Personal Computer, Smartphone, Tablet |
| Image Aspect Ratio | 16:10 |
| Maximum Focal Length | 1.4 |
| Minimum Focal Length | 1.4 Millimeters |
| Video Capture Format | AVI |
| Warranty Description | 6 month |
| Are Batteries Included | No |
| Has Image Stabilization | No |
| Item Dimensions D x W x H | 1.5"D x 1.5"W x 1.2"H |
| Display Resolution Maximum | 1920x1200 Pixels |
| Effective Still Resolution | 2 MP |
| Effective Video Resolution | 1200 Pixels |
